40M IR 8MP Motorized Vari-Focal Lens Dome - DI-380IPSN-MVF-G-V3
40M IR 8MP Motorized Vari-Focal Lens Dome - DI-380IPSN-MVF-G-V3 - Image 2
40M IR 8MP Motorized Vari-Focal Lens Dome - DI-380IPSN-MVF-G-V3 - Image 3

40M IR 8MP Motorized Vari-Focal Lens Dome – DI-380IPSN-MVF-G-V3

Login, Register, or Call for Price

40m IR 8MP Motorized Vari-Focal Lens Large Dome/Turret Camera With Built-in Check Point Protection
SKU: DI-380IPSN-MVF-G-V3 Category:
Free Shipping for orders over $600 (AU Only)*
Brand:

Description

40m IR 8MP Motorized Vari-Focal Lens Large Dome/Turret Camera With Built-in Check Point Protection – Grey

Equipped with a 2.8-12mm motorized lens, this 8MP Dome/Turret camera is designed for medium-distance surveillance (up to 40m) in indoor and outdoor scenarios.

The camera offers outstanding DDA Analytics (Detect, Distinguish, Alert), which can perform human and vehicle recognition. The camera is cyber-protected round the clock with the integrated Check Point Quantum IoT Nano agent that provides an advanced threat prevention layer against the common attack vectors at runtime.

With its excellent performance, reliability, and affordable price, the DI-380IPSN-MVF-G-V3 is the perfect solution for any basic installation.


Israeli made professional high quality security cameras for professional installations.  Please contact us for a quote to purchase Provision-ISR or register for a trade account to access pricing.


DI-380IPSN-MVF-V3-features

DI-380IPSN-MVF-G-V3 Features

3rd Party Cyber Protection

General
Quantum IoT Nano agent by Check Point™
Protection Methods
Shell injection protection, File Monitor, Import-Table Protection, Dynamic-Memory Protection

NDAA Compliant

NDAA Compliant
Yes

Video

Image Sensor
1/2.8″ CMOS (16:9)
Effective Pixels
3840×2160
Electronic Shutter
1s ~ 1/100000s
Day & Night
ICR
Min. Illumination
0.02 lux (@F1.6, AGC on) 0 lux with IR on

Audio

Audio compression
G.711A/G.711U
Communication
One-Way Audio


Image Settings
AWB, AGC Adjustable, Exposure Mode (Auto) Sharpness, Saturation, Brightness & Contrast Adjustable
Image Enhancement
True WDR, BLC, HLC, ROI
Noise Reduction
3D-DNR
Image Orientation
Mirror/Flip
Privacy Zone
Yes

Events and Analytics

Analytics
General Analytics: Camera Tampering AI (Object Recognition): DDA Sterile Area, DDA Line Crossing
Motion Detection
Yes

Compression

Resolution
8MP / 6MP / 5MP / 4MP / 2MP / 1MP / D1 / QVGA / CIF
Frame Rate
8MP @ 1-20FPS, 6MP @ 1-25/30FPS, 5MP @ 1-25/30FPS, 4MP @ 1-25/30FPS, 2MP 1-25/30FPS
Video Compression
H.265+/ H.264+ / H.265 / H.264 / MJPEG**
Multi-Stream
Master Stream: 4K(3840×2160) (1~20fps)/ 6MP(3072×2048) / 5MP(2592×1944) / 2K(2560×1440) / 2MP(1920×1080) Substream: 2MP/1MP/D1/CIF/QCIF Third Stream: 1MP/D1/CIF/QCIF (1~30fps)
Bit Rate
64Kbps ~ 8Mbps@H.265 / 64Kbps ~ 8Mbps@H.264
Encode Mode
VBR/CBR
Image Quality
Five levels under VBR; Free adjustment under CBR

Lens

Lens (Field of View)
2.8-12mm MVF with Auto Focus (102°- 32.1°)
Iris
DC Iris
Lens Mount
Ø14 Mount
Detect
2.8~12mm(W): 85.71m(281.20ft) – 2.8~12mm(T): 272.75m(894.84ft)
Recognize
2.8~12mm(W): 17.14m(56.23ft) – 2.8~12mm(T): 54.55m(178.96ft)
Identify
2.8~12mm(W): 8.57m(28.11ft) – 2.8~12mm(T): 27.27m(89.46ft)

Network

User Access
Supports simultaneous monitoring of up to 10 users with multi-stream real-time transmission
Network Protocol
IPv4, IPv6, TCP, UDP, DHCP, NTP, DDNS, 802.1X, RTSP, Multicast, UPnP, Email, FTP, HTTPS, QoS, P2P
Remote Monitoring
IE Browsing (Plug-In required), Chrome/Edge/Safari/Firefox plug-in free browsing, Ossia VMS Software, Provision Cam2 Mobile App
Ethernet
100Mbps
ONVIF
Profile S/G

Connectivity

Network
RJ45 (+PoE)
Audio Connectivity
Built-in Microphone + Audio input
Alarm
No
SD Card
Event/Schedule based Main/Substream recording (Up to 256Gb)
Wiegand
No
Power
DC Socket
Analog Video Output
No

Housing

PoE
Yes
Illumination
40m (3 High-Power IR LED)
Power Supply
DC12V/~900mA / PoE/~10W
Protection Rate
Water Proof: IP67
Work Environment
-30°C~60°C, 10%~90% Humidity
Bracket
3-Axis Bracket
Dimensions
Ø113mm×99.6mm
Weight (gross)
~640g
Hard Reset Button
Yes


DI-380IPSN-MVF-G-V3 Datasheet

Software:

Ossia Video Player

Register for Member Pricing

Latest VMS Version

IP Tool Archive

40m IR 8MP Motorized Vari-Focal Lens Large Dome/Turret Camera With Built-in Check Point Protection – Grey

Equipped with a 2.8-12mm motorized lens, this 8MP Dome/Turret camera is designed for medium-distance surveillance (up to 40m) in indoor and outdoor scenarios.

The camera offers outstanding DDA Analytics (Detect, Distinguish, Alert), which can perform human and vehicle recognition. The camera is cyber-protected round the clock with the integrated Check Point Quantum IoT Nano agent that provides an advanced threat prevention layer against the common attack vectors at runtime.

With its excellent performance, reliability, and affordable price, the DI-380IPSN-MVF-G-V3 is the perfect solution for any basic installation.


Israeli made professional high quality security cameras for professional installations.  Please contact us for a quote to purchase Provision-ISR or register for a trade account to access pricing.


DI-380IPSN-MVF-V3-features

DI-380IPSN-MVF-G-V3 Features

3rd Party Cyber Protection

General
Quantum IoT Nano agent by Check Point™
Protection Methods
Shell injection protection, File Monitor, Import-Table Protection, Dynamic-Memory Protection

NDAA Compliant

NDAA Compliant
Yes

Video

Image Sensor
1/2.8″ CMOS (16:9)
Effective Pixels
3840×2160
Electronic Shutter
1s ~ 1/100000s
Day & Night
ICR
Min. Illumination
0.02 lux (@F1.6, AGC on) 0 lux with IR on

Audio

Audio compression
G.711A/G.711U
Communication
One-Way Audio


Image Settings
AWB, AGC Adjustable, Exposure Mode (Auto) Sharpness, Saturation, Brightness & Contrast Adjustable
Image Enhancement
True WDR, BLC, HLC, ROI
Noise Reduction
3D-DNR
Image Orientation
Mirror/Flip
Privacy Zone
Yes

Events and Analytics

Analytics
General Analytics: Camera Tampering AI (Object Recognition): DDA Sterile Area, DDA Line Crossing
Motion Detection
Yes

Compression

Resolution
8MP / 6MP / 5MP / 4MP / 2MP / 1MP / D1 / QVGA / CIF
Frame Rate
8MP @ 1-20FPS, 6MP @ 1-25/30FPS, 5MP @ 1-25/30FPS, 4MP @ 1-25/30FPS, 2MP 1-25/30FPS
Video Compression
H.265+/ H.264+ / H.265 / H.264 / MJPEG**
Multi-Stream
Master Stream: 4K(3840×2160) (1~20fps)/ 6MP(3072×2048) / 5MP(2592×1944) / 2K(2560×1440) / 2MP(1920×1080) Substream: 2MP/1MP/D1/CIF/QCIF Third Stream: 1MP/D1/CIF/QCIF (1~30fps)
Bit Rate
64Kbps ~ 8Mbps@H.265 / 64Kbps ~ 8Mbps@H.264
Encode Mode
VBR/CBR
Image Quality
Five levels under VBR; Free adjustment under CBR

Lens

Lens (Field of View)
2.8-12mm MVF with Auto Focus (102°- 32.1°)
Iris
DC Iris
Lens Mount
Ø14 Mount
Detect
2.8~12mm(W): 85.71m(281.20ft) – 2.8~12mm(T): 272.75m(894.84ft)
Recognize
2.8~12mm(W): 17.14m(56.23ft) – 2.8~12mm(T): 54.55m(178.96ft)
Identify
2.8~12mm(W): 8.57m(28.11ft) – 2.8~12mm(T): 27.27m(89.46ft)

Network

User Access
Supports simultaneous monitoring of up to 10 users with multi-stream real-time transmission
Network Protocol
IPv4, IPv6, TCP, UDP, DHCP, NTP, DDNS, 802.1X, RTSP, Multicast, UPnP, Email, FTP, HTTPS, QoS, P2P
Remote Monitoring
IE Browsing (Plug-In required), Chrome/Edge/Safari/Firefox plug-in free browsing, Ossia VMS Software, Provision Cam2 Mobile App
Ethernet
100Mbps
ONVIF
Profile S/G

Connectivity

Network
RJ45 (+PoE)
Audio Connectivity
Built-in Microphone + Audio input
Alarm
No
SD Card
Event/Schedule based Main/Substream recording (Up to 256Gb)
Wiegand
No
Power
DC Socket
Analog Video Output
No

Housing

PoE
Yes
Illumination
40m (3 High-Power IR LED)
Power Supply
DC12V/~900mA / PoE/~10W
Protection Rate
Water Proof: IP67
Work Environment
-30°C~60°C, 10%~90% Humidity
Bracket
3-Axis Bracket
Dimensions
Ø113mm×99.6mm
Weight (gross)
~640g
Hard Reset Button
Yes


DORI Distance

(Note: The DORI distance is a “general proximity” of distance which makes it easy to pinpoint the right camera for your needs. The DORI distance is calculated based on sensor specification and lab test result according to EN 62676-4 which defines the criteria for Detect, Observe, Recognize and Identify respectively.)

Model
DI-380IPSN-MVF-G-V3

Detect (25px/m)
85.6m (Wide)
273m (Tele)

Observe (63px/m)
34m (Wide)
108m (Tele)

Recognise (125px/m)
17m (Wide)
54m (Tele)

Identify (250px/m)
8.5m (Wide)
27 (Tele)

Register for Member Pricing

Note: Wide is for minimum zoom and Tele is for Maximum Zoom

For more information on selecting a CCTV camera please see this post:

Choosing the right CCTV camera for your application.
