Compact Series 4CH PoE NVR with 1 x HDD Bay
Sale!
Compact Series 4CH PoE NVR with 1 x HDD Bay - Image 2
Compact Series 4CH PoE NVR with 1 x HDD Bay - Image 3

Compact Series 4CH PoE NVR with 1 x HDD Bay

Original price was: $313.50.Current price is: $222.38.

Compact 4 Channel Network Video Recorder with PoE (80Mbps)

Out of stock

SKU: NVR4COM3 Category: Tag:
Free Shipping for orders over $600 (AU Only)*
Brand:

Description

The NVR4COM3 is a compact network video recorder with Ultra HD broadcast-quality image performance and built-in 4 port power over Ethernet switch, allowing easy plug and play installation. It features the latest H.265+ compression technology and an industrial grade processor.

Product features:

  • Records up to 4K Ultra HD resolution (3840 x 2160)
  • 4CH NVR with 4 Power over Ethernet ports
  • Up to 80Mbps total incoming bandwidth
  • 1 x SATA port up to 10TB, max. 10TB HDD capacity
  • Motion detection recording & record scheduling
  • HDMI & VGA simultaneous video output
  • Backup via external USB device or local network
  • Remote view in seconds with setup via QR code

Specification

Register for Member Pricing

Alarm Input / Output
N/A

Auxiliary Inputs
N/A

Backup Modes
USB Device / Network

Bit Rate
N/A

Decoding Capability
4 channels @ 4.0MP (25fps)

Dimensions
260mm x 225mm x 48mm

Display Resolution
Configurable from 3840 x 2160 to 1024 x 768

Display Split
1/4

Ethernet
1 RJ-45 port (10/100Mbps)

HDD Modes
Single (no RAID compatibility)

Incoming Bandwidth
80Mbps for access / 80Mbps for storage / 60Mbps for forwarding

Internal HDD
1 x SATA port up to 10TB, max. 10TB HDD capacity

Interoperability
ONVIF (Profile S), CGI, SDK, RTSP

Main Processor
Industrial grade embedded processor

Max. User Access
128 users

Network Functions
HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, P2P

Operating Environment
-10 ~+55°C / 10~90%RH

Operating System
Embedded Linux

Optical Interface
N/A

OSD
Camera title, Time, Video loss, Camera lock, Motion detection, Recording

Playback Sync
1/4

PoE
Yes

Power Consumption
NVR: <10W (without HDD) / PoE: Max 25.5W per port, 36W total

Power over Ethernet
4 ports (IEEE802.3at/af, 10/100Mbps)

Power Supply
48 ~ 53VDC / 1.13 ~ 1.25A

Rackmount Units
Compact 1RU

Rackmountable
No

Record Interval
N/A

Record Modes
Manual / Schedule (Regular [Continuous], Motion Detection, Alarm, Timed) / Stop

Recording Resolution
Configurable from 8.0MP (3840 x 2160) to CIF (352 x 288)

Remote View
iOS (iPhone, iPad) / Android devices

Search Modes
Time/Date, Alarm, Motion Detection, Exact Search (to the second), Smart Search

Trigger Events
Recording, PTZ, Tour, Alarm, Video Push, Email, FTP, Snapshot, Buzzer, Screentips, Log

Two-way Talk
1 channel input, 1 channel output, RCA

USB Interface
2 ports: Rear USB2.0 / Front USB2.0

Video Compression
H.265+ / H.265 / H.264+ / H.264

Video Detection
General: Motion Detection, Smart Motion Detection, Video Loss, Privacy Masking, IPC Alarm / Anomlay: Device Offline, Storage Error, Network Security, IP/MAC Conflict

Video Input
4 channels

Video Output
1 HDMI / 1 VGA

Weight
0.86kg (without HDD)

Warranty (years)
4



Download documents from the following links:

Watchguard_NVRxCOM3_Datasheet_PDF

VIP Vision _ Watchguard NVR Installation Manual – Black GUI (PDF)

Register for Member Pricing

Full NVR User Manual V4.3.0 – Blue GUI (PDF)

Full NVR User Manual V4.5.1 – Black GUI (PDF)

VIP Vision _ Watchguard Mobile App Quick Start Guide (PDF)

Register for Member Pricing
