Box Camera 4MP CS Mount - BX-341-IPE
Box Camera 4MP CS Mount - BX-341-IPE
Box Camera 4MP CS Mount - BX-341-IPE

Box Camera 4MP CS Mount – BX-341IPEN

Login, Register, or Call for Price

4MP IP Camera • Eye-Sight v2 Series • NDAA Certified • Real-Time • CS MOUNT
SKU: BX-341IPEN Category:
Free Shipping for orders over $600 (AU Only)*
Brand:

Description

4MP DDA Analytics Box Camera

Depending on the attached lens, this 4MP box camera is designed for medium-high distance surveillance.

The camera offers broad possibilities for Analytics, from Face Detection to the outstanding DDA Analytics (Detect, Distinguish, Alert), which can perform object recognition and object counting. With various detection rules and triggers, the BX-341IPEN camera will help the user end false alarms.

Israeli made professional high quality security cameras for professional installations.  Please contact us for a quote to purchase Provision-ISR or register for a trade account to access pricing.

Register for Member Pricing

BX-341IPEN-features

BX-341IPEN Features

3rd Party Cyber Protection

General
N/A
Protection Methods
N/A

NDAA Compliant

NDAA Compliant
Yes

Video

Image Sensor
1/3″ CMOS (16:9)
Effective Pixels
2592×1520
Electronic Shutter
1/3s ~ 1/10000s
Day & Night
ICR
Min. Illumination
Day: 0.0028lux / Night: 0.001lux (@F1.2, AGC on)

Audio

Audio compression
G.711A/G.711U
Communication
Two-Way Audio


Image Settings
AWB, AGC Adjustable, Exposure Mode (Auto) Sharpness, Saturation, Brightness & Contrast Adjustable
Image Enhancement
True WDR (120dB), BLC, HLC, ROI
Noise Reduction
3D-DNR
Image Orientation
Mirror/Flip
Privacy Zone
Yes

Events and Analytics

Analytics
General Analytics: Camera Tampering AI (Object Recognition): DDA Sterile Area, DDA Line Crossing, DDA Object Counting (Line), DDA Object Counting (Area), DDA Loitering Detection, DDA Illegal Parking Detection AI (Face Detection): 10 Faces per frame AI: Heatmap DDA2: Advanced Object Classification Audio Exception
Motion Detection
Yes

Compression

Resolution
4MP / 2K / 3MP / 2MP / 1MP / D1 / QVGA / CIF / QCIF
Frame Rate
1-25/30FPS in Normal Mode. 1-50/60FPS in HFR Mode**
Video Compression
H.265+/ H.264+ / H.265 / H.264 / MJPEG**
Multi-Stream
Master Stream: 4MP (2592×1520) / 2K (2560×1440) / 3MP / 2MP / 1MP Substream: 1MP / D1 / CIF / QCIF Third Stream: D1 / CIF / QCIF (1~30fps)
Bit Rate
64Kbps ~ 7Mbps@H.265 / 64Kbps ~ 8Mbps@H.264
Encode Mode
VBR/CBR
Image Quality
Five levels under VBR; Free adjustment under CBR

Lens

Lens (Field of View)
N/A
Iris
Depends on Lens
Lens Mount
CS Mount

Network

User Access
Supports simultaneous monitoring of up to 10 users with multi-stream real-time transmission
Network Protocol
IPv4, IPv6, TCP, UDP, DHCP, NTP, DDNS, 802.1X, RTSP, Multicast, UPnP, Email, FTP, HTTPS, QoS, P2P
Remote Monitoring
IE Browsing (Plug-In required), Chrome/Edge/Safari/Firefox plug-in free browsing, Ossia VMS Software, Provision Cam2 Mobile App
Ethernet
100Mbps
ONVIF
Profile T/S/G

Connectivity

Network
RJ45 (+PoE)
Audio Connectivity
Audio input + Audio output
Alarm
2Ch input, 2Ch output
SD Card
Event/Schedule based Main/Substream recording (Up to 256Gb)
Wiegand
No
Power
DC Socket
Analog Video Output
CVBS (BNCx1)

Housing

PoE
Yes
Illumination
N/A
Power Supply
DC12V~320mA / AC24V~160mA / PoE~6W
Protection Rate
None
Work Environment
-30°C~60°C, 10%~90% Humidity
Bracket
No
Dimensions
79W × 160.8D × 64H mm
Weight (gross)
~500g
Hard Reset Button
Yes

[/themify_list]
