20M 4MP IR Fixed Lens Dome – DI-340IPEN-28-V4

Login, Register, or Call for Price

20m IR 4mp DDA Analytics Fixed Lens Small Dome/Turret Camera With Built-in Check Point Protection and Dual System technology

SKU: DI-340IPEN-28-V4 Category: IP EYE-SIGHT-V2

Free Shipping for orders over $600 (AU Only)*

Brand: Provision-ISR

Description

20m IR 4mp DDA Analytics Fixed Lens Small Dome/Turret Camera With Built-in Check Point Protection and Dual System technology

Equipped with a 2.8mm fixed lens, this 4MP camera is designed for short-distance surveillance (up to 20m) in indoor and outdoor scenarios.

Fitted with the new “Dual System” technology, the camera can deal with internal anomalies independently, making it more redundant to software-based issues.

The camera offers broad possibilities for Analytics, from Face Detection to the outstanding DDA Analytics (Detect, Distinguish, Alert) and the newly developed DDA2, which can perform object recognition, object counting, and investigate specifics such as age, color, gender, vehicle brand and much more. The DI-340IPEN-28-V4 camera is here to end false alarms.

Check Point Quantum IoT Nano agent is integrated into this model. It provides an advanced threat prevention layer against the common attack vectors at runtime.

Israeli made professional high quality security cameras for professional installations. Please contact us for a quote to purchase Provision-ISR or register for a trade account to access pricing.

DI-340IPEN-28-V4 Features

3rd Party Cyber Protection

General

Quantum IoT Nano agent by Check Point™

Protection Methods

Shell injection protection, File Monitor, Import-Table Protection, Dynamic-Memory Protection

NDAA Compliant

Yes

Video

Image Sensor

1/3″ CMOS (16:9)

Effective Pixels

2592×1520

Electronic Shutter

1/2s ~ 1/100000s

Day & Night

ICR

Min. Illumination

Day: 0.1lux / Night: 0.005lux (@F1.6, AGC on) 0lux with IR on

Audio

Audio compression

G.711A/G.711U

Communication

Two-Way Audio


Image Settings

AWB, AGC Adjustable, Exposure Mode (Auto) Sharpness, Saturation, Brightness & Contrast Adjustable

Image Enhancement

True WDR (120dB), BLC, HLC, ROI

Noise Reduction

3D-DNR

Image Orientation

Mirror/Flip

Privacy Zone

Yes

Events and Analytics

Analytics

General Analytics: Camera Tampering AI (Object Recognition): DDA Sterile Area, DDA Line Crossing, DDA Object Counting (Line), DDA Object Counting (Area) AI (Face Detection): 10 Faces per frame AI: Heatmap DDA2: Advanced Object Classification

Motion Detection

Yes

Compression

Resolution

4MP (2592×1520) / 3MP (2304×1296) / 2MP (1920×1080) / D1 / QVGA /CIF

Frame Rate

1-25/30FPS

Video Compression

H.265+/ H.264+ / H.265 / H.264 / MJPEG**

Multi-Stream

Master Stream: 4MP(2592×1520) / 2K (2560×1440) / 3MP / 2MP / 1MP Substream: 1MP/QVGA/D1/CIF Third Stream: QVGA/D1/CIF (1~30fps)

Bit Rate

64Kbps ~ 4Mbps@H.265 / 64Kbps ~ 6Mbps@H.264

Encode Mode

VBR/CBR

Image Quality

Five levels under VBR; Free adjustment under CBR

Lens

Lens (Field of View)

2.8mm (96°)

Iris

Fixed Iris

Lens Mount

M12 Mount

Detect

60.69m(199.11ft)

Recognize

12.14m(39.82ft)

Identify

6.07m(19.91ft)

Network

User Access

Supports simultaneous monitoring of up to 10 users with multi-stream real-time transmission

Network Protocol

IPv4, IPv6, TCP, UDP, DHCP, NTP, DDNS, 802.1X, RTSP, Multicast, UPnP, Email, FTP, HTTPS, QoS, P2P

Remote Monitoring

IE Browsing (Plug-In required), Chrome/Edge/Safari/Firefox plug-in free browsing, Ossia VMS Software, Provision Cam2 Mobile App

Ethernet

100Mbps

ONVIF

Profile T/S/G

Connectivity

Network

RJ45 (+PoE)

Audio Connectivity

Built-in Microphone + Audio input + Audio output

Alarm

SD Card

Event/Schedule based Main/Substream recording (Up to 256Gb)

Wiegand

Power

DC Socket

Analog Video Output

Technician Port

Housing

PoE

Yes

Illumination

20m (1 High-Power IR LED)

Power Supply

DC12V/~450mA / PoE/~7W

Protection Rate

Water Proof: IP67

Work Environment

-30°C~60°C, 10%~90% Humidity

Bracket

3-Axis Bracket

Dimensions

Ø97mm×82.6mm

Weight (gross)

~540g

Hard Reset Button

Yes

Documents

DI-340IPEN-28-V4 Datasheet

v5.x 320IPEN 340IPEN FL Series Manual

Software:

Latest CMS Version

Latest CMS for MAC

Latest IP Tool

20m IR 4mp DDA Analytics Fixed Lens Small Dome/Turret Camera With Built-in Check Point Protection and Dual System technology

Equipped with a 2.8mm fixed lens, this 4MP camera is designed for short-distance surveillance (up to 20m) in indoor and outdoor scenarios.

Fitted with the new “Dual System” technology, the camera can deal with internal anomalies independently, making it more redundant to software-based issues.

Check Point Quantum IoT Nano agent is integrated into this model. It provides an advanced threat prevention layer against the common attack vectors at runtime.

Israeli made professional high quality security cameras for professional installations. Please contact us for a quote to purchase Provision-ISR or register for a trade account to access pricing.

DI-340IPEN-28-V4 Features

3rd Party Cyber Protection

General

Quantum IoT Nano agent by Check Point™

Protection Methods

Shell injection protection, File Monitor, Import-Table Protection, Dynamic-Memory Protection

NDAA Compliant

Yes

Video

Image Sensor

1/3″ CMOS (16:9)

Effective Pixels

2592×1520

Electronic Shutter

1/2s ~ 1/100000s

Day & Night

ICR

Min. Illumination

Day: 0.1lux / Night: 0.005lux (@F1.6, AGC on) 0lux with IR on

Audio

Audio compression

G.711A/G.711U

Communication

Two-Way Audio


Image Settings

AWB, AGC Adjustable, Exposure Mode (Auto) Sharpness, Saturation, Brightness & Contrast Adjustable

Image Enhancement

True WDR (120dB), BLC, HLC, ROI

Noise Reduction

3D-DNR

Image Orientation

Mirror/Flip

Privacy Zone

Yes

Events and Analytics

Analytics

Motion Detection

Yes

Compression

Resolution

4MP (2592×1520) / 3MP (2304×1296) / 2MP (1920×1080) / D1 / QVGA /CIF

Frame Rate

1-25/30FPS

Video Compression

H.265+/ H.264+ / H.265 / H.264 / MJPEG**

Multi-Stream

Master Stream: 4MP(2592×1520) / 2K (2560×1440) / 3MP / 2MP / 1MP Substream: 1MP/QVGA/D1/CIF Third Stream: QVGA/D1/CIF (1~30fps)

Bit Rate

64Kbps ~ 4Mbps@H.265 / 64Kbps ~ 6Mbps@H.264

Encode Mode

VBR/CBR

Image Quality

Five levels under VBR; Free adjustment under CBR

Lens

Lens (Field of View)

2.8mm (96°)

Iris

Fixed Iris

Lens Mount

M12 Mount

Detect

60.69m(199.11ft)

Recognize

12.14m(39.82ft)

Identify

6.07m(19.91ft)

Network

User Access

Supports simultaneous monitoring of up to 10 users with multi-stream real-time transmission

Network Protocol

IPv4, IPv6, TCP, UDP, DHCP, NTP, DDNS, 802.1X, RTSP, Multicast, UPnP, Email, FTP, HTTPS, QoS, P2P

Remote Monitoring

IE Browsing (Plug-In required), Chrome/Edge/Safari/Firefox plug-in free browsing, Ossia VMS Software, Provision Cam2 Mobile App

Ethernet

100Mbps

ONVIF

Profile T/S/G

Connectivity

Network

RJ45 (+PoE)

Audio Connectivity

Built-in Microphone + Audio input + Audio output

Alarm

SD Card

Event/Schedule based Main/Substream recording (Up to 256Gb)

Wiegand

Power

DC Socket

Analog Video Output

Technician Port

Housing

PoE

Yes

Illumination

20m (1 High-Power IR LED)

Power Supply

DC12V/~450mA / PoE/~7W

Protection Rate

Water Proof: IP67

Work Environment

-30°C~60°C, 10%~90% Humidity

Bracket

3-Axis Bracket

Dimensions

Ø97mm×82.6mm

Weight (gross)

~540g

Hard Reset Button

Yes

DORI Distance

(Note: The DORI distance is a “general proximity” of distance which makes it easy to pinpoint the right camera for your needs. The DORI distance is calculated based on sensor specification and lab test result according to EN 62676-4 which defines the criteria for Detect, Observe, Recognize and Identify respectively.)

Model

DI-340IPEN-28-V4

Detect (25px/m)

59m

Observe (63px/m)

23m

Recognise (125px/m)

11.8m

Identify (250px/m)

5.9m

For more information on selecting a CCTV camera please see this post: Choosing the right CCTV camera for your application.
