Every angle of your vehicle covered with the Securview VSCVI-2DIR. This camera delivers a wide field of view and 1080p Full HD video streaming, in a durable and compact shock-resistant housing. Ideal for vehicle interiors, eg. buses, taxis.
Camera features:
Streams Full HD 1080p/2.0MP (1920 x 1080)
Fixed 2.8mm lens; 101° viewing angle
Up to 500m HD video transmission over coax
Infrared illumination up to 20m
IP67 weather resistance
Built-in microphone on camera
Auto white balance & 2D noise reduction
Shock-resistant metal chassis & cable connectors
Specifications
General
Image Sensor
1/2.7” 2.0 Megapixel CMOS
Max. Resolution
1080p Full HD
Effective Pixels
1920 (H) x 1080 (V)
Signal Noise Ratio
> 65dB
Camera
Lens
2.8mm F2.0 Fixed Lens
Lens Type
Fixed
Angle of View
101° (H), 54° (V), 119° (D)
Focus
Fixed / 0.5m Min. Focus Distance
Minimum Illumination
0.02 Lux at F2.0 (Colour) / 0 Lux IR Active
Electronic Shutter
1/25 ~ 1/100000s
Day/Night
Auto (ICR) / Manual
Infrared Range
20m
White Balance
Auto / Manual
Noise Reduction
2D
Gain Control
Auto
Lighting Compensation
BLC / HLC / DWDR
DORI Distance (Note: The DORI distance is a “general proximity” of distance which makes it easy to pinpoint the right camera for your needs. The DORI distance is calculated based on sensor specification and lab test result according to EN 62676-4 which defines the criteria for Detect, Observe, Recognize and Identify respectively.)
Detect (25px/m)
38.6m
Observe (63px/m)
15.4m
Recognise (125px/m)
7.7m
Identify (250px/m)
3.9m
Video
Resolution
1080p (1920 x 1080) to CIF (352 x 288)
Frame Rate
25fps (1080p and lower)
Transmission Distance
3m / 6m / 12m / 18m heavy duty cables available
Interface
Audio Input
Built-in microphone
Alarm Interface
N/A
Video Output
1 x BNC HDCVI/CVBS/AHD/TVI switchable video output (aviation connector)
Mobile Series 1080p Fixed HDCVI Mini Dome – VSCVIM-2DIR
$90.09Original price was: $90.09.$78.33Current price is: $78.33.Description
Every angle of your vehicle covered with the Securview VSCVI-2DIR. This camera delivers a wide field of view and 1080p Full HD video streaming, in a durable and compact shock-resistant housing. Ideal for vehicle interiors, eg. buses, taxis.
Camera features:
Specifications
Download documents from the following links:
Securview_M_Series_Mobile_Cameras_Datasheet_PDF
