Akuvox SIP 7″ Wi-Fi Android touch video intercom monitor – C315W

The Akuvox C315W is a low cost 7″ Android touch screen monitor with Wi-Fi for use with Akuvox SIP video intercom door stations.  It also includes an 8 zone security system for added securty in your home.  You can view IP cameras and the door station from the touch interface.  Call other intercom monitors for a room to room voice intercom system. Powered by PoE for an easy installation.

The C315W multifunctional communicator, with an Android operating system, provides audio and video communication with Door phones via SIP 2.0 protocol. It delivers the ultimate touch screen experience in an unobtrusive, space-saving design featuring a brilliant 7 inch capacitive touch screen display.

At a Glance:

Touch Screen Display

Display Type: Active matrix TFT, transmissive type
Size: 7 inch (176 mm) diagonal
Aspect Ratio: 16:9
Resolution: 1024×600
Brightness: 300nits (cd/m²)
Contrast: 800:1
Color Depth: 24-bit, 16M colors
Illumination: Edgelit LED
Viewing Angle: ±70° horizontal, ±70° vertical
Touch Screen: Projected Capacitive

Video
Streaming Formats: H.264

Audio
Features: Built-in microphone and speaker

Memory
RAM: 1GB
Flash: 8GB

Interface
Ethernet: 2×10/100 Mbps ports, auto-switching, auto-discovery, auto-negotiating, full/half duplex, DHCP, IEEE802.3af compliant
Relay Out: 1x relay out (NO/COM/NC)
Alarm In: 8x alarm input terminals
Bell In: 1x bell input terminal
RS485: 1x RS485 communication port

Environmental
Temperature: 14° to 112°F (-10° to 45°C)
Humidity: 10% to 90% (non-condensing)

Mechanical parameters
Dimensions (W x H x D): 200 x 132 x 17.5 mm

Application Scenario
