Shop » Products » IP CCTV » Provision-ISR IP CCTV » IP SMART-SIGHT » 12MP Fixed Lens Fish-Eye Camera with IR LED – FEI-2120IPN
IR Vandal-Proof Fish Eye 6MP IP PoE Camera - FEI-360IP5-v2
12MP Fixed Lens Fish-Eye Camera with IR LED - FEI-2120IPN - Image 2

12MP Fixed Lens Fish-Eye Camera with IR LED – FEI-2120IPN

Login, Register, or Call for Price

IR Vandal-Proof Fish Eye 12MP IP PoE Camera with NDAA Certification
SKU: FEI-2120IPN Categories: ,
Free Shipping for orders over $600 (AU Only)*
Brand:

Description

12MP Fixed Lens Fisheye Camera with IR LED


The FEI-2120IPN is a 12MP panoramic fisheye camera designed to deliver 360° wide-angle surveillance, making it ideal for large open spaces such as retail floors, lobbies, and warehouses. With its fixed lens and integrated IR LED, it ensures comprehensive coverage both day and night.

Register for Member Pricing

The camera comes equipped with a built-in microphone, Digital WDR, BLC, HLC, and 3D-DNR, enabling clear image capture in challenging lighting conditions. Capable of replacing multiple fixed-focus lens cameras, this versatile unit offers a cost-effective and space-saving solution for total area monitoring

Israeli made, professional, high quality security cameras for professional installations.  Please contact us for a quote to purchase Provision-ISR or register for a trade account to access pricing.

Register for Member Pricing

features-smart-sight-cpe-fixed-12mp-fe

FEI-2120IPN Features

3rd Party Cyber Protection

General
Quantum IoT Nano agent by Check Point™
Protection Methods
Shell injection protection, File Monitor, Import-Table Protection, Dynamic-Memory Protection

NDAA Compliant

NDAA Compliant
Yes

Video

Image Sensor
1/1.7″ CMOS (3000 x 3000 – 16:9)
Effective Pixels
3000×3000 (1:1)
Electronic Shutter
1/3s ~ 1/100000s
Day & Night
ICR
Min. Illumination
0.01lux (@F2.0, AGC on) 0lux with IR on

Audio

Audio compression
G.711A/G.711U
Communication
Two-Way Audio


Image Settings
AWB, AGC Adjustable, Exposure Mode (Auto) Sharpness, Saturation, Brightness & Contrast Adjustable
Image Enhancement
Digital WDR, BLC, HLC, ROI
Noise Reduction
3D-DNR
Image Orientation
360
Privacy Zone
Yes

Events and Analytics

Analytics
AI: DDA Human Only in Ceiling Installation: Line Crossing, Sterile Area, Area Entry, Area Exit, Object Counting, Heat Map AI: DDA all objects: in Wall/Desktop Installation: Line Crossing, Sterile Area, Area Entry, Area Exit, Object Counting
Motion Detection
Yes

Compression

Resolution
12MP(4000×3000), 9MP(3000×3000), 5MP(2160×2160), 2MP(1080×1080) , 960×960, 720×720, 480×480
Frame Rate
1-25/30FPS
Video Compression
H.265+/ H.264+ / H.265 / H.264 / MJPEG**
Multi-Stream
Mode1: Fisheye Fisheye view (main stream): 3000×3000/2160×2160/1080×1080 (50Hz: 1~25fps; 60Hz: 1~30fps) Fisheye view (sub stream): 1440×1440/720×720/480×480 (50Hz: 1~25fps; 60Hz: 1~30fps) Fisheye view (third stream): 960×960/ 640×640/360×360(50Hz: 1~25fps; 60Hz: 1~30fps) Mode2: Panoramic Panoramic view (main stream): 4000×3000/3840×2160/3200×1800/2560×1440 (50Hz:1~20fps; 60Hz:1~20fps) Panoramic view (sub stream): 1920×1080/ 960×540/640×480 (50Hz:1~20fps; 60Hz:1~20fps) Panoramic view (third stream): 1280×720/640×360 (50Hz:1~20fps; 60Hz:1~20fps) Mode 3: Fisheye+Panoramic+3 PTZ Fisheye view (main stream): 3000×3000/2160×2160/1080×1080 (50Hz: 1~15fps; 60Hz:1~15fps) Fisheye view (sub stream): 1440×1440/720×720/480×480 (50Hz: 1~15fps; 60Hz:1~15fps) Fisheye view (third stream): 960×960/ 640×640/360×360 (50Hz: 1~15fps; 60Hz:1~15fps) Panoramic view (main stream): 4000×3000/3840×2160/3200×1800/2560×1440 (50Hz:1~10fps; 60Hz: 1~10fps) Panoramic view (sub stream): 1920×1080/ 960×540/640×480 (50Hz:1~10fps; 60Hz: 1~10fps) Panoramic view (third stream): 1280×720/640×360(50Hz:1~10fps; 60Hz: 1~10fps) 3PTZ view: (1280×720) * 3 (50Hz:1~15fps; 60Hz: 1~15fps) Mode 4 Fisheye+ 4 PTZ Fisheye view (main stream): 3000×3000/2160×2160/1080×1080 (50Hz: 1~25fps; 60Hz:1~30fps) Fisheye view (sub stream): 1440×1440/720×720/480×480 (50Hz: 1~25fps; 60Hz:1~30fps) Fisheye view (third stream): 960×960/ 640×640/360×360 (50Hz: 1~25fps; 60Hz:1~30fps) 4PTZ view : (1280×720) * 4 (50Hz:1~15fps; 60Hz: 1~15fps) Mode5 Fisheye+ 4 PTZ Fusion Fisheye view (main stream): 3000×3000/2160×2160/1080×1080 (50Hz: 1~25fps; 60Hz:1~30fps) Fisheye view (sub stream): 1440×1440/720×720/480×480 (50Hz: 1~25fps; 60Hz:1~30fps) Fisheye view (third stream): 960×960/ 640×640/360×360 (50Hz: 1~25fps; 60Hz:1~30fps) 4PTZ fusion view (main stream): 2560×1440 (50Hz:1~20fps; 60Hz: 1~20fps) 4PTZ fusion view (sub stream): 640×360 (50Hz:1~20fps; 60Hz: 1~20fps)
Bit Rate
128Kbps ~ 16Mbps@H.265 / 128Kbps ~ 16Mbps@H.264
Encode Mode
VBR/CBR
Image Quality
Five levels under VBR; Free adjustment under CBR

Lens

Lens (Field of View)
1.65mm (360° for Ceiling Mount / 180° For Wall Mount)
Iris
Fixed Iris
Lens Mount
M12 Mount

Network

User Access
Supports simultaneous monitoring of up to 6 users with multi-stream real-time transmission
Network Protocol
IPv4, IPv6, TCP, UDP, DHCP, NTP, DDNS, 802.1X, RTSP, Multicast, UPnP, Email, FTP, HTTPS, QoS
Remote Monitoring
IE Browsing, Ossia VMS Software, Provision Cam2 Mobile App
Ethernet
100Mbps
ONVIF
Profile S/G

Connectivity

Network
RJ45 (+PoE)
Audio Connectivity
Built-In Microphone + Audio Input + Audio Output
Alarm
Alarm in + Alarm out
SD Card
Event/Schedule based Main/Substream recording (Up to 256GB)
Wiegand
N/A
Power
DC Socket
Analog Video Output
CVBS (BNCx1)

Housing

PoE
Yes
Illumination
15m (4 High-Power IR LEDs)
Power Supply
DC12V/~700mA / PoE/~10.5W
Protection Rate
Water Proof: IP67
Work Environment
-30°C~60°C, 10%~90% Humidity
Bracket
No
Dimensions
?130mm×46mm
Weight (gross)
~530g
Hard Reset Button
Yes

Documents

FEI-2120IPN Datasheet
FEI-360IPN User Manual

Software:

Register for Member Pricing

Latest CMS Version

Latest CMS for MAC

Latest IP Tool

Register for Member Pricing

12MP Fixed Lens Fisheye Camera with IR LED


The FEI-2120IPN is a 12MP panoramic fisheye camera designed to deliver 360° wide-angle surveillance, making it ideal for large open spaces such as retail floors, lobbies, and warehouses. With its fixed lens and integrated IR LED, it ensures comprehensive coverage both day and night.

Register for Member Pricing

The camera comes equipped with a built-in microphone, Digital WDR, BLC, HLC, and 3D-DNR, enabling clear image capture in challenging lighting conditions. Capable of replacing multiple fixed-focus lens cameras, this versatile unit offers a cost-effective and space-saving solution for total area monitoring

Israeli made, professional, high quality security cameras for professional installations.  Please contact us for a quote to purchase Provision-ISR or register for a trade account to access pricing.

Register for Member Pricing

features-smart-sight-cpe-fixed-12mp-fe

FEI-2120IPN Features

3rd Party Cyber Protection

General
Quantum IoT Nano agent by Check Point™
Protection Methods
Shell injection protection, File Monitor, Import-Table Protection, Dynamic-Memory Protection

NDAA Compliant

NDAA Compliant
Yes

Video

Image Sensor
1/1.7″ CMOS (3000 x 3000 – 16:9)
Effective Pixels
3000×3000 (1:1)
Electronic Shutter
1/3s ~ 1/100000s
Day & Night
ICR
Min. Illumination
0.01lux (@F2.0, AGC on) 0lux with IR on

Audio

Audio compression
G.711A/G.711U
Communication
Two-Way Audio


Image Settings
AWB, AGC Adjustable, Exposure Mode (Auto) Sharpness, Saturation, Brightness & Contrast Adjustable
Image Enhancement
Digital WDR, BLC, HLC, ROI
Noise Reduction
3D-DNR
Image Orientation
360
Privacy Zone
Yes

Events and Analytics

Analytics
AI: DDA Human Only in Ceiling Installation: Line Crossing, Sterile Area, Area Entry, Area Exit, Object Counting, Heat Map AI: DDA all objects: in Wall/Desktop Installation: Line Crossing, Sterile Area, Area Entry, Area Exit, Object Counting
Motion Detection
Yes

Compression

Resolution
12MP(4000×3000), 9MP(3000×3000), 5MP(2160×2160), 2MP(1080×1080) , 960×960, 720×720, 480×480
Frame Rate
1-25/30FPS
Video Compression
H.265+/ H.264+ / H.265 / H.264 / MJPEG**
Multi-Stream
Mode1: Fisheye Fisheye view (main stream): 3000×3000/2160×2160/1080×1080 (50Hz: 1~25fps; 60Hz: 1~30fps) Fisheye view (sub stream): 1440×1440/720×720/480×480 (50Hz: 1~25fps; 60Hz: 1~30fps) Fisheye view (third stream): 960×960/ 640×640/360×360(50Hz: 1~25fps; 60Hz: 1~30fps) Mode2: Panoramic Panoramic view (main stream): 4000×3000/3840×2160/3200×1800/2560×1440 (50Hz:1~20fps; 60Hz:1~20fps) Panoramic view (sub stream): 1920×1080/ 960×540/640×480 (50Hz:1~20fps; 60Hz:1~20fps) Panoramic view (third stream): 1280×720/640×360 (50Hz:1~20fps; 60Hz:1~20fps) Mode 3: Fisheye+Panoramic+3 PTZ Fisheye view (main stream): 3000×3000/2160×2160/1080×1080 (50Hz: 1~15fps; 60Hz:1~15fps) Fisheye view (sub stream): 1440×1440/720×720/480×480 (50Hz: 1~15fps; 60Hz:1~15fps) Fisheye view (third stream): 960×960/ 640×640/360×360 (50Hz: 1~15fps; 60Hz:1~15fps) Panoramic view (main stream): 4000×3000/3840×2160/3200×1800/2560×1440 (50Hz:1~10fps; 60Hz: 1~10fps) Panoramic view (sub stream): 1920×1080/ 960×540/640×480 (50Hz:1~10fps; 60Hz: 1~10fps) Panoramic view (third stream): 1280×720/640×360(50Hz:1~10fps; 60Hz: 1~10fps) 3PTZ view: (1280×720) * 3 (50Hz:1~15fps; 60Hz: 1~15fps) Mode 4 Fisheye+ 4 PTZ Fisheye view (main stream): 3000×3000/2160×2160/1080×1080 (50Hz: 1~25fps; 60Hz:1~30fps) Fisheye view (sub stream): 1440×1440/720×720/480×480 (50Hz: 1~25fps; 60Hz:1~30fps) Fisheye view (third stream): 960×960/ 640×640/360×360 (50Hz: 1~25fps; 60Hz:1~30fps) 4PTZ view : (1280×720) * 4 (50Hz:1~15fps; 60Hz: 1~15fps) Mode5 Fisheye+ 4 PTZ Fusion Fisheye view (main stream): 3000×3000/2160×2160/1080×1080 (50Hz: 1~25fps; 60Hz:1~30fps) Fisheye view (sub stream): 1440×1440/720×720/480×480 (50Hz: 1~25fps; 60Hz:1~30fps) Fisheye view (third stream): 960×960/ 640×640/360×360 (50Hz: 1~25fps; 60Hz:1~30fps) 4PTZ fusion view (main stream): 2560×1440 (50Hz:1~20fps; 60Hz: 1~20fps) 4PTZ fusion view (sub stream): 640×360 (50Hz:1~20fps; 60Hz: 1~20fps)
Bit Rate
128Kbps ~ 16Mbps@H.265 / 128Kbps ~ 16Mbps@H.264
Encode Mode
VBR/CBR
Image Quality
Five levels under VBR; Free adjustment under CBR

Lens

Lens (Field of View)
1.65mm (360° for Ceiling Mount / 180° For Wall Mount)
Iris
Fixed Iris
Lens Mount
M12 Mount

Network

User Access
Supports simultaneous monitoring of up to 6 users with multi-stream real-time transmission
Network Protocol
IPv4, IPv6, TCP, UDP, DHCP, NTP, DDNS, 802.1X, RTSP, Multicast, UPnP, Email, FTP, HTTPS, QoS
Remote Monitoring
IE Browsing, Ossia VMS Software, Provision Cam2 Mobile App
Ethernet
100Mbps
ONVIF
Profile S/G

Connectivity

Network
RJ45 (+PoE)
Audio Connectivity
Built-In Microphone + Audio Input + Audio Output
Alarm
Alarm in + Alarm out
SD Card
Event/Schedule based Main/Substream recording (Up to 256GB)
Wiegand
N/A
Power
DC Socket
Analog Video Output
CVBS (BNCx1)

Housing

PoE
Yes
Illumination
15m (4 High-Power IR LEDs)
Power Supply
DC12V/~700mA / PoE/~10.5W
Protection Rate
Water Proof: IP67
Work Environment
-30°C~60°C, 10%~90% Humidity
Bracket
No
Dimensions
?130mm×46mm
Weight (gross)
~530g
Hard Reset Button
Yes
