8CH 12MP Face Recognition PoE NVR with Alarms – NVR12-8200PFAN

Login, Register, or Call for Price

8 Channel NVR (Via PoE/Network) • NDAA Certified • Output: HDMI(4K)/VGA • Recording resolution – up to 12 Megapixels • Small 1U Case, 1 HDD • Audio In/Out • Alarm In/Out

SKU: NVR12-8200PFAN Category: Provision-ISR NVR

Free Shipping for orders over $600 (AU Only)*

Brand: Provision-ISR

Description

Input: 8 Channel (Via PoE/Network) • NDAA • Output: HDMI(4K)/VGA • Recording resolution – up to 12 Megapixels • Small 1U Case, 1 HDD • Audio In/Out • Alarm In/Out

Record 8 channels of up to 12MP with analytics – Face Recognition, Smart Search, Camera Tampering, Line Crossing, Sterile Area, Object Monitoring.

Playback to 4K monitor in real time.

Connect IP cameras to PoE ports on this model and maximum of 80Mb/s incoming or outgoing stream.

NDAA Certified.

Israeli made, professional, high quality security cameras for professional installations. Please contact us for a quote to purchase Provision-ISR or register for a trade account to access pricing.

NVR12-8200PFAN Features

3rd Party Cyber Protection

General

N/A

Protection Methods

N/A

NDAA Compliant

Yes

Video

Video Input

8Ch over Network

Output

HDMI (4K@60Hz, 4K@30Hz, 1080P), VGA (1080P, 1280×1024, 1024×768)

View Mode

Mirrored

Fish-Eye Dewarp

Local + Web

Decoding Format

H.265 / H.265+ / H.265S / H.264

Decoding Capabilities

1Ch – 12MP ; 4Ch – 2MP ; 8CH – D1

Audio

Audio-specs-Input

1CH RCA (Linear, 1k?) + IPC inputs

audio-specs-Output

1CH RCA (2.0 Vp-p, 1 k?) + IPC outputs

Compression

G.711A/G.711U

Two Way Audio

Yes

Analytics

Supported Analytics

Camera Tampering, DDA2 With Object Classification, Line Crossing (DDA / Pixel Based), Sterile Area (DDA / Pixel Based), Object Monitoring, Object Counting (DDA), Crowd Gathering, People Intrusion, Smart Search, Face Recognition, LPR, Thermal. Advanced Face Recognition Mode: Supports up to 2 Non-AI IPCs and performs face detection and recognition.

Analytics Channels (IPC Based)

8Ch (Requires supporting IPC)

Analytic Channels (NVR Based)

Up to 2Ch DDA1 (Sterile Area/Line Crossing) or Up to 2Ch Face Detection + Recognition or Up to 6Ch Face Recognition (or their combinations)

Face Recognition Rate

18 Faces per second (6Ch supported)

Bandwidth

Incoming

80Mbps

Outgoing

80Mbps

Record/ Main Stream

Real-Time Recording

8CH 8MP real-time 12MP – 20FPS

Record Type

Video / Video + Audio

Recording Modes

Schedule, Manual, Motion, Sensor, Analytics, POS and all of its combinations

16MP

N/A

12MP

160FPS(PAL/NTSC)

8MP

240FPS(NTSC)/200FPS(PAL)

5MP and lower

240FPS(NTSC)/200FPS(PAL)

Master stream over network

Up to 12CH@Recording Resolution

Substream

Resolution substream

Depends on IPC

Remote view

Max Channel View

40Ch (Limited to outgoing Bandwidth Capacity)

Remote Applications

User Access

64 Users online with Professional Authority Management

Mobile App

Provision Cam2 for iOS/Android

PC/Mac Software

Ossia VMS Standard / Enterprise

Plug-in free Web-Browser

Chrome, FireFox, Safari, Edge, Opera. (All Limited to 4Ch Live View / Playback)

Plug-in based Web-Browser

Internet Exporer

Playback

Local

8Ch

Remote

8Ch

Search Mode

DDA Object, Smart Search, LPR, Face Recognition, Time-Slice, Time, Event, POS

Backup

USB

2 USB 2.0 Port + 1 USB 3.0 Port

Backup Format

AVI (Unencrypted) / Private Format (Encrypted / Unencrypted)

Alarm

Alarm-in

8+IPC

Alarm-out

4+IPC

Storage

HDD

E-Sata Support

RAID

N/A

PTZ

Connection

via Network

Supported Controls

Pan, Tilt, Zoom, Preset, Cruise, Scan, Iris, Focus

RS-485

Yes (C06 Keyboard Connection)

Network

Ethernet

10/100Mbps self-adaptive Ethernet interface

Protocols

TCP/IPv4/IPv6, DHCP, DDNS, NTP, SMTP, SSL/TLS, UPnP, P2P, RTSP, FTP, HTTPS, 820.1X, SNMP, Auto Report (Ossia VMS)

ONVIF

Full Device Support (Profile T/G, ONVIF Version 20.12)

PoE

PoE Ports

8xRJ45

Speed

10/100Mbps (10Mbps under CCTV Mode)

Standard

IEEE802.3AF/AT

CCTV Mode

Yes (Up to 200m and 10Mbps bandwidth)

Total Power

80W (Average 10W per Channel)

Max. Power Output (Per Ch.)

N/A

Others

Power Supply

12VDC/2A

Power consumption (No HDD)

20W

Dimension

W300xD250xH50mm

Operation Temperature

0°C~50°C

Documents

NVR12-8200PFAN

Ossia NVR User Manual
