“Ultimate AI Series 4.0MP Motorised Bullet (8 ~32mm lens) – VSIPU-4BIRM-IZ” has been added to your cart. View cart

Compact AI 16 Channel Network Video Recorder

Sale!

Compact AI Series 16CH PoE NVR with 2 x HDD Bays – NVR16COM-I

Name: Compact AI Series 16CH PoE NVR with 2 x HDD Bays - NVR16COM-I
Brand: Watchguard
SKU: NVR16COM-I
Availability: InStock

Original price was: $725.00.Current price is: $625.20.

4 Interest Free Payments of $156.30

Compact AI 16 Channel Network Video Recorder

SKU: NVR16COM-I Categories: VIP / Watchguard System Builder NVR, Watchguard / VIP Vision AI Network Surveillance, Network Video Recorder (NVR)

Free Shipping for orders over $600 (AU Only)*

Brand: Watchguard

Description

The NVR16COM-I offers advanced technologies to transform the way surveillance works for you. Monitor your operations with greater efficiency, security & reliability using intelligent face recognition, people/vehicle identification & more. Identify strangers & VIPs, create blacklists, search footage playback and receive intelligent alerts to your devices for highly reliable security notifications.

Product features:

Record beyond Ultra HD up to 16.0MP (4920 x 3264)
200Mbps incoming bandwidth (80Mbps with AI)
2 x SATA ports for up to 20TB HDD storage
Built in PoE switch (ePoE & EoC support for ports 1-8)
Native Ultra HD live view on 4K monitors via HDMI
Perimeter protection for up to 4 channels for accurate vehicle and people detection
Identify people with 2 channels for face recognition
AI face searching for up to 8 faces at once (12 faces/sec)
Receive face recognition & perimeter alerts on device(s)

Specification

GENERAL

Interoperability

ONVIF 2.4, SDK,CGI

Main Processor

Multi-core Embedded Processor

Operating System

Embedded Linux OS

Two-way Talk

1 Channel Input, 1 Channel Output, RCA

Video Input

16 Channels

DISPLAY

Display Resolution

Configurable from 3840 x 2160 to 1024 x 768

Display Split

1/4/8/9/16

OSD

Camera title, Time, Video loss, Camera lock, Motion detection, Recording

Video Output

1 x HDMI, 1 x VGA

RECORDING

Decoding Capacity

2 channel: 8.0MP (30fps) / 8 channel: 1080p (30fps)

Incoming Bandwidth

200Mbps (80Mbps when AI function is enabled)

Record Interval

1~120 min (default: 60 min) / Pre-record: 1~30s / Post-record: 10~300s

Record Modes

Manual, Schedule (Continuous, MD (Motion Detection), Alarm, IVS)

Recording Resolution

Configurable from: 16.0MP (4920 x 3264) to D1 (704 x 480)

Video Compression

H.265+ / H.265 / H.264+ / H.264 / MJPEG

FACE RECOGNITION

AI Search (Face Recognition)

Up to 8 target face images at the same time

Database Application

Each database can be applied to video channels independently

Database Management

Up to 10 face databases with 20,000 face images in total. Name, gender, birthday, nationality, address, ID information can be added to each face picture

Performance (Face Recognition)

Max. 12 face pictures per second (modeling and comparing)

Stranger Mode

Detect strangers face (not in database)

Trigger Events (Face Recognition)

Buzzer, Voice Prompts, Email, snapshot, Recording, Alarm Out, PTZ activation, etc.

PERIMETER PROTECTION

AI Search (Perimeter Protection)

Search by target classification (Human, Vehicle)

Object Classification

Human / vehicle secondary recognition for tripwire and intrusion

Performance (Perimeter Protection)

4 Channels, 10 IVS rules for each Channel

METADATA

AI Search (Metadata)

Support search target video by metadata

Face

Gender, age, glasses, beard, mask

Human Body

Tops style, tops colour, bottom style, bottom colour, hat , bag

Non-motor Vehicle

Type, colour, people, number

Vehicle

Vehicle colour, vehicle model, vehicle logo, plate colour, vehicle decorations, call, seatbelt

FEATURES

Alarm Input / Output

4 channel alarm inputs / 2 channel relay output

Backup Modes

USB Device / Network

Playback Sync

1/4/9/16

Search Modes

Time / Date, Alarm, MD & Exact Search (to the second)

Trigger Events

Buzzer, Voice Prompts, Email, snapshot, Recording, Alarm Out, PTZ activation, etc.

Video Detection

Motion Detection, MD Zones: 396 (22 x 18), Video Loss, Tampering & Scene Change

NETWORK

Ethernet

1 RJ45 Ports (10/100/1000Mbps)

Max. User Access

128 users

Network Functions

HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, SNMP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Center, IP Search (Support IP camera, DVR, NVS, etc.), P2P

Optical Interface

N/A

Power over Ethernet

16 Ports (IEE802.3af/at), 1-8 Ports Support ePoE & EoC

Remote View

IOS (iPhone,iPad), Android Devices

STORAGE

Auxiliary Inputs

1 x RS232

HDD Modes

N/A

Internal HDD
