Akuvox Black E12W Surface Mount Video Intercom with one Button, Card Reader, and WiFi

Akuvox E12W Black – VoIP (SIP) Indoor Video Door Station, IR Sensor, Surface Mount, Relay, RFID Reader, and WiFi

The Black Akuvox E12W is a smart SIP-based indoor entry phone. It can be connected with Akuvox indoor phone, mobile phone App, or any other compatible SIP based video device for unlock and monitor.

Unlock with RFID cards or fobs, and Smartphone via Bluetooth or NFC.

Purchase with a monitor and pay $0 for the Cloud App licence for up to 4 smart phones. Purchase without a monitor and pay for the Cloud App.

The E12W allows the resident to check callers through the 2MP camera, even at night due to the LED White light for illumination. The E12W has 1 relay for opening doors, is powered by 12VDC or PoE, and has an IR sensor.

The slim body of the E12W is ideal for mounting where space is limited, even on narrow door frames.

Requires a suitable power source – PoE injector or PoE switch or 12VDC power supply.  Please add one if required or contact us for assistance

Akuvox E12W At a Glance

Akuvox E12W Specifications

Physical & Power

• Front panel: Plastic – Black
• Camera.2M pixels, automatic lighting
• Button: 1 call button with backlight
• Light sensor: Yes
• Wiegand port: Yes
• RF card reader: 13. 56MHz & NFC
• Relays out: 1
• Inputs: 2
• Microphone: – 40dB
• Speaker: 8?/ 1.5W
• Ethernet port: RJ45, 10/100Mbps adaptive
• 802.3af Power- over- Ethernet
• 12V DC connector (if not using PoE)
• Installation: Wall-mounted
• Wall-mounted DIM: 146 x 70 x 23mm
• Working Humidity: 10~90%
• Working Temperature: -40°C ~ +60°C
• Storage’ Temperature: -40°C ~ +70°C

Networking

Protocols support: IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP

Video

• Sensor: 1/2.7″, CMOS
• Pixels: CIF, QCIF, VGA, 4CIF, 720p, 1080p
• Video codec: H.264, H.265
• Video resolution: up to 1920x1080p
• Max. image transfer rate: 1080p – 25fps
• Viewing angle: 123°(H) / 609°(V)
• White LEDs for picture lighting during dark hours with internal light senso
• Compatible with 3rd Party Video components, e.g. NVRs

Audio

• SIP v1 (RFC2543), SIP v2 (RFC3261)
• Narrowband audio codec: G.711a, G.711?, G.729
• Broadband audio codec: G.722
• DTMF: In-band, out-of-band
• DTMF (RFC2833), SIP Info
• Echo Cancellation
• Voice Activation Detection
• Comfort Noise Generator

Door Entry Feature

• Relays controlled individually by DTMF tones
• Camera permanently operational
• Auto-night mode with LED illumination
• White balance: auto
• Minimum illumination: 0.1LUX

Deployment & Maintenance

• Auto- Provisioning
• Web management portal
• Web- based packet dump
• Configuration backup/ restore
• Entry log export
• Access table export / import
• Firmware upgrade
• System logs (include door access logs)

Akuvox E12W Application Scenario

• Remote site entry over Internet
• Apartment/flat intercom with door access control
