40M IR 2MP Vari-Focal Bullet – I4-320IPSN-VF-V4

Login, Register, or Call for Price

40m IR 2MP Vari-Focal Lens Medium Bullet Camera With Built-in Check Point Protection and Dual System technology
SKU: I4-320IPSN-VF-V4 Category:
Free Shipping for orders over $600 (AU Only)*
Brand:

Description

40m IR 2MP Vari-Focal Lens Medium Bullet Camera With Built-in Check Point Protection and Dual System technology

Equipped with a 2.8-12mm Vari-Focal lens, this 2MP Dome camera is designed for medium-distance surveillance (up to 40m) in indoor and outdoor scenarios.

Fitted with the new “Dual System” technology, the camera can deal with internal anomalies independently, making it more redundant to software-based issues.

The camera offers outstanding DDA Analytics (Detect, Distinguish, Alert), which can perform human and vehicle recognition. With various detection rules and triggers, the I4-320IPSN-VF-V4 camera is here to end false alarms and, with the Check Point protection, ensures that your devices are cyber-protected round the clock.

Israeli made professional high quality security cameras for professional installations.  Please contact us for a quote to purchase Provision-ISR or register for a trade account to access pricing.

I4-320IPSN-VF-V4-features

I4-320IPSN-VF-V4 Features

3rd Party Cyber Protection

General
N/A
Protection Methods
N/A

NDAA Compliant

NDAA Compliant
Yes

Video

Image Sensor
1/2.8″ CMOS (16:9)
Effective Pixels
1920×1080
Electronic Shutter
1/3s ~ 1/10000s
Day & Night
ICR
Min. Illumination
0.006 lux (@F1.6, AGC on) 0 lux with IR on

Audio

Audio compression
G.711A/G.711U
Communication
One-Way Audio


Image Settings
AWB, AGC Adjustable, Exposure Mode (Auto) Sharpness, Saturation, Brightness & Contrast Adjustable
Image Enhancement
True WDR, BLC, HLC, ROI
Noise Reduction
3D-DNR
Image Orientation
Mirror/Flip
Privacy Zone
Yes

Events and Analytics

Analytics
General Analytics: Camera Tampering AI (Object Recognition): DDA Sterile Area, DDA Line Crossing
Motion Detection
Yes

Compression

Resolution
2MP (1920×1080) / D1 (704×576) / QVGA (480×240) / CIF (352×288)
Frame Rate
1-25/30FPS
Video Compression
H.265+/ H.264+ / H.265 / H.264 / MJPEG**
Multi-Stream
Master Stream: 2MP (1920×1080) / 1MP (1280×720) (1~30fps) Substream: 1MP/QVGA/D1/CIF Third Stream: D1/CIF (1~30fps)
Bit Rate
64Kbps ~ 4Mbps@H.265 / 64Kbps ~ 6Mbps@H.264
Encode Mode
VBR/CBR
Image Quality
Five levels under VBR; Free adjustment under CBR

Lens

Lens (Field of View)
2.8-12mm VF with Auto Focus (100°-33°)
Iris
Fixed Iris
Lens Mount
Ø14 Mount
Detect
2.8~12mm(W): 43.13m(141.50ft) – 2.8~12mm(T): 131.90m(432.74ft)
Recognize
2.8~12mm(W): 8.63m(28.31ft) – 2.8~12mm(T): 26.38m(86.54ft)
Identify
2.8~12mm(W): 4.31m(14.14ft) – 2.8~12mm(T): 13.19m(43.27ft)

Network

User Access
Supports simultaneous monitoring of up to 3 users with multi-stream real-time transmission
Network Protocol
IPv4, IPv6, TCP, UDP, DHCP, NTP, DDNS, 802.1X, RTSP, Multicast, UPnP, Email, FTP, HTTPS, QoS, P2P
Remote Monitoring
IE Browsing (Plug-In required), Chrome/Edge/Safari/Firefox plug-in free browsing, Ossia VMS Software, Provision Cam2 Mobile App
Ethernet
100Mbps
ONVIF
Profile T/S/G

Connectivity

Network
RJ45 (+PoE)
Audio Connectivity
Built-in Microphone + Audio input
Alarm
No
SD Card
Event/Schedule based Main/Substream recording (Up to 256Gb)
Wiegand
No
Power
DC Socket
Analog Video Output
No

Housing

PoE
Yes
Illumination
40m (2 High-Power IR LED)
Power Supply
DC12V/~550mA / PoE/~7W
Protection Rate
Water Proof: IP67
Work Environment
-30°C~60°C, 10%~90% Humidity
Bracket
3-Axis Bracket
Dimensions
220.8×79.4×81.2mm
Weight (gross)
~770g
Hard Reset Button
Yes

Register for Member Pricing

Documents

I4-320IPSN-VF-V4 Datasheet

320IPS 340IPS 380IPS S-Series v2 NDAA Manual (All Models)

Register for Member Pricing

Software:

Latest CMS Version

Latest CMS for MAC

Register for Member Pricing

Latest IP Tool

40m IR 2MP Vari-Focal Lens Medium Bullet Camera With Built-in Check Point Protection and Dual System technology

Equipped with a 2.8-12mm Vari-Focal lens, this 2MP Dome camera is designed for medium-distance surveillance (up to 40m) in indoor and outdoor scenarios.

Fitted with the new “Dual System” technology, the camera can deal with internal anomalies independently, making it more redundant to software-based issues.

The camera offers outstanding DDA Analytics (Detect, Distinguish, Alert), which can perform human and vehicle recognition. With various detection rules and triggers, the I4-320IPSN-VF-V4 camera is here to end false alarms and, with the Check Point protection, ensures that your devices are cyber-protected round the clock.

Israeli made professional high quality security cameras for professional installations.  Please contact us for a quote to purchase Provision-ISR or register for a trade account to access pricing.

I4-320IPSN-VF-V4-features

I4-320IPSN-VF-V4 Features

3rd Party Cyber Protection

General
N/A
Protection Methods
N/A

NDAA Compliant

NDAA Compliant
Yes

Video

Image Sensor
1/2.8″ CMOS (16:9)
Effective Pixels
1920×1080
Electronic Shutter
1/3s ~ 1/10000s
Day & Night
ICR
Min. Illumination
0.006 lux (@F1.6, AGC on) 0 lux with IR on

Audio

Audio compression
G.711A/G.711U
Communication
One-Way Audio


Image Settings
AWB, AGC Adjustable, Exposure Mode (Auto) Sharpness, Saturation, Brightness & Contrast Adjustable
Image Enhancement
True WDR, BLC, HLC, ROI
Noise Reduction
3D-DNR
Image Orientation
Mirror/Flip
Privacy Zone
Yes

Events and Analytics

Analytics
General Analytics: Camera Tampering AI (Object Recognition): DDA Sterile Area, DDA Line Crossing
Motion Detection
Yes

Compression

Resolution
2MP (1920×1080) / D1 (704×576) / QVGA (480×240) / CIF (352×288)
Frame Rate
1-25/30FPS
Video Compression
H.265+/ H.264+ / H.265 / H.264 / MJPEG**
Multi-Stream
Master Stream: 2MP (1920×1080) / 1MP (1280×720) (1~30fps) Substream: 1MP/QVGA/D1/CIF Third Stream: D1/CIF (1~30fps)
Bit Rate
64Kbps ~ 4Mbps@H.265 / 64Kbps ~ 6Mbps@H.264
Encode Mode
VBR/CBR
Image Quality
Five levels under VBR; Free adjustment under CBR

Lens

Lens (Field of View)
2.8-12mm VF with Auto Focus (100°-33°)
Iris
Fixed Iris
Lens Mount
Ø14 Mount
Detect
2.8~12mm(W): 43.13m(141.50ft) – 2.8~12mm(T): 131.90m(432.74ft)
Recognize
2.8~12mm(W): 8.63m(28.31ft) – 2.8~12mm(T): 26.38m(86.54ft)
Identify
2.8~12mm(W): 4.31m(14.14ft) – 2.8~12mm(T): 13.19m(43.27ft)

Network

User Access
Supports simultaneous monitoring of up to 3 users with multi-stream real-time transmission
Network Protocol
IPv4, IPv6, TCP, UDP, DHCP, NTP, DDNS, 802.1X, RTSP, Multicast, UPnP, Email, FTP, HTTPS, QoS, P2P
Remote Monitoring
IE Browsing (Plug-In required), Chrome/Edge/Safari/Firefox plug-in free browsing, Ossia VMS Software, Provision Cam2 Mobile App
Ethernet
100Mbps
ONVIF
Profile T/S/G

Connectivity

Network
RJ45 (+PoE)
Audio Connectivity
Built-in Microphone + Audio input
Alarm
No
SD Card
Event/Schedule based Main/Substream recording (Up to 256Gb)
Wiegand
No
Power
DC Socket
Analog Video Output
No

Housing

PoE
Yes
Illumination
40m (2 High-Power IR LED)
Power Supply
DC12V/~550mA / PoE/~7W
Protection Rate
Water Proof: IP67
Work Environment
-30°C~60°C, 10%~90% Humidity
Bracket
3-Axis Bracket
Dimensions
220.8×79.4×81.2mm
Weight (gross)
~770g
Hard Reset Button
Yes
Register for Member Pricing

DORI Distance

(Note: The DORI distance is a “general proximity” of distance which makes it easy to pinpoint the right camera for your needs. The DORI distance is calculated based on sensor specification and lab test result according to EN 62676-4 which defines the criteria for Detect, Observe, Recognize and Identify respectively.)

Model
I4-320IPSN-VF-V4

Detect (25px/m)
50m (Wide)
126m (Tele)

Observe (63px/m)
19m (Wide)
50m (Tele)

Recognise (125px/m)
10m (Wide)
25m (Tele)

Identify (250px/m)
5m (Wide)
12 (Tele)

Register for Member Pricing

Note: Wide is for minimum zoom and Tele is for Maximum Zoom

For more information on selecting a CCTV camera please see this post:

Choosing the right CCTV camera for your application.
